W24 series Angle Rolls Machines

  • High-efficiency
  • Full function
  • High rolling quality

W24 series Angle Rolls Machines is also called Profile Bending Machine.

We can bend square and round profiles, tubes, and pipes with the help of special rolls (molds).

The angle roll bending machine works both vertically and horizontally based on the end user’s specific needs.

Get Quote
W24 series Angle Rolls Machines Features

1. Full hydraulic transmission, electrical centralize control, digital readout, once feeding without return to finish bending and pre-bending and other processes.

2. Top roller fixed, two bottom rollers move by arc lifting around a fixed center. They can rise and fall separately also can rising and falling at the same time.

3. Three drive rolls mounted with hydraulic motor, without slipping, even for thinner material can be bent.

4. Side guide rollers to ensure high quality for asymmetrical Section Bending.

5. Full function, the various profiles can be bent by replacing the mold.

6. Vertical and horizontal optional

7. NC or CNC can be optional by customer.

W24 series Angle Rolls Machines Technical Specification
Technical data W24S
Max. bending resistant modulus 6 16 30 45 75 100 140 180 260 320 400 500
Max. bending resistant modulus 6 16 30 45 75 100 140 180 250 320 400 500
Bending speed(m/min) 6 5 4
Yield Limit(mpa) 245Mpa
Angle, inner bending Max.section size(mm) 40×5 70×8 80×8 90×10 100×10 120×12 140×16 150×16 160×16 180×14 200×18 200×20
Angle, outer bending Max.section size(mm) 50×5 80×8 90×10 100×10 120×12 140×16 150×16 160×16 180×14 200×18 200×24 250×25
Channel, outer bending Channel size (mm) 8 12 16 20 25 28 30 32 36 40 45 50
Channel, inner bending Channel size (mm) 8 12 16 20 25 28 30 32 36 40 45 50
Plate, flat bending Max.section size(mm) 100×8 150×25 180×25 200×30 220×40 250×40 280×50 300×50 330×50 360×60 400×75 500×76
Plate, vertical bending Max.section size(mm) 50×12 75×16 90×20 100×25 110×4 12×40 150×40 180×30 190×40 190×50 200×50 200×60
Tube bending Max.section size(mm) 42×4 76×4.5 89×5 89×8 114×5 159×5 168×6 168×8 219×8 245×8 273×8 323×10
Rod bending Max.section size(mm) 38 52 62 75 85 90 100 110 120 135 150 160
Square bending Max.section size(mm) 45×3 60×4 70×4 80×6 90×8 100×10 125×10 140×10 150×10 165×10 180×12 200×12
Main Components of W24 series Angle Rolls Machines

Hydraulic System

Bending moulds

Control System

Electric System

Motor

Application Industries

This Profile Bending Machine is high-efficiency equipment used to bend all kinds of profiles such as angle, channel, I-beam, flat bar, square tube, tube, pipe and so on. Once feeding then finish bending and pre-bending. It is widely in the petrol, chemical, shipyard, metalworking and machine manufacturing industries.
